| NO. | Item | Unit |
|
| 1 | Item NO. |
| GYC-M | GYC-S |
| 2 | Installation |
| with Rail | Side installtaion without rail |
| 3 | Input voltage | V | 110 or 220 @60Hz | 110 or 220 @60Hz |
| 4 | Rated motor power | W | 280 | 280 |
| 5 | Speed | mm/s | 100~140 | 100~140 |
| 6 | Max lifting height | m | 7 | 5 |
| 7 | Working temp. | ℃ | -25~+45 | -25~+45 |
| 8 | Max operation intensity | Cycle per hour | 25 | 25 |
| 9 | Max continuous operations | cycle | 15 | 15 |
| 10 | Transmission |
| Belt deceleration; secondary sprocket deceleration | Belt deceleration; secondary sprocket deceleration |
| 11 | Motor protection |
| Overvoltage and thermal protections | Overvoltage and thermal protections |
| 12 | Position limits set |
| Mechanical | Mechanical |
| 13 | Brake |
| with brake device | with Brake device |
| 14 | Emergency operation |
| Manual chain | Emergency Release |
| 15 | RH requirement |
| <70% | <70% |
